Impression 3D scanner

A desktop 3D scanner designed specifically for acquiring impressions, triple trays and bite.

High Accuracy

iScan offers maximum precision and accuracy, acquiring even the smallest details, allowing an extremely detailed reconstruction and offering powerful tools for cloud point management. Up to 10 microns, tested in metrological environment.

Open System

iScan works with open and standard formats, allowing the individual components of the product to be used together with third-party products that support the same formats. The data can be exported in the most common formats to be read by any CAD/CAM system.

Plug & Play

Supplied with DentalCad software, the pre-installed EGS proprietary software and an integrated PC, iScan is fully Plug & Play. Only a monitor and a mouse are required to use the scanner.

Technical Specifications


3D scanning Technology

Camera Resolution

Interface

Light Source

Rotary Stage

3D acquisition Volume (WxDxH)

Accuracy

Input/Output Formats

Size (WxHxD)

Weight

3D scanning of the verticulator

CPU

GPU

SSD

Memory

Input/Output

OS

Acquisition Speed

Structured Light

1.3 Megapixels

USB 3.0

LED, 100 ANSI-lumens – Blue Light

2 axis movement (rotation, tilting)

90mm x 80mm x 55mm

0.010 mm

STL, PLY, OBJ, ASC

250mm x 450mm x 450mm

16 kg

Yes

6th Generation Intel “Core” series i7 6700 3.4 Ghz

Nvidia “GeForce” GT 730 1GB DDR3

256 GB SATA

16 GB RAM DDR3. Memory Speed 1600 Mhz

1 HDMI, 1 DVI-D, 1 DisplayPort, 6 USB 3.0, Ethernet 10/100/1000 Mbps, WiFi 802.11 abgnac

Windows 10 Pro – 64 bit

25 fps (frame per second)

Discover The Features Of iScan
