High Accuracy

It offers maximum precision and accuracy, acquiring even the smallest detail, allowing a highly detailed reconstruction and offering powerful point cloud management tools.

Up to 0.015 mm accuracy, tested in a metrological environment.

Maximum Reliability

JScan was developed entirely by EGS, including Lumen acquisition software, for greater reliability, speed and efficiency.

High quality mechanical and electronic components.

Open System

JScan works with open and standard formats, allowing individual product components to be used together with third-party products that support the same formats.

Datasets can be exported in open formats, which can be read using any CAD/CAM system.

Plug & Play

Supplied with Leios software and an integrated PC already installed, JScan is fully Plug&Play. Only a monitor and a mouse are required to use the scanner.

OTHER FEATURES

AUTOMATIC CALIBRATION

Thanks to its special plate, the calibration of the optics and axis is done automatically in 5 minutes.

CUSTOMIZABLE

Complete freedom of choice: customize your hardware and / or software product in the way that best meets your needs.

TECHNICAL SPECIFICATIONS


3D scanning Technology

Camera Resolution

Interface

Light Source

Rotary Stage

3D acquisition Volume (WxDxH)

Accuracy

Input/Output Formats

Size (WxHxD)

Weight

3D scanning of the verticulator

CPU

GPU

SSD

Memory

Input/Output



OS

Acquisition Speed

Structured Light

1.3 Megapixels

USB 2.0

LED, 100 ANSI-lumens – Blue Light

2 axis movement (rotation, tilting)

90mm x 80mm x 55mm

0.015 mm

STL, PLY, OBJ, ASC

250mm x 450mm x 450mm

16 kg

Yes

6th Generation Intel “Core” series i7 6700 3.4 Ghz

Nvidia “GeForce” GT 730 1GB DDR3

256 GB SATA

16 GB RAM DDR3. Memory Speed 1600 Mhz

1 HDMI, 1 DVI-D, 1 DisplayPort, 6 USB 3.0, Ethernet 10/100/1000 Mbps, WiFi 802.11 a\b\g\n\ac

Windows 10 Pro – 64 bit

12 fps (frame per second)

CERTIFICATION AND METROLOGICAL TESTS

Discover The Features Of JScan 3
